Model : TFT-008CCH2E1-M; TFT-010CCH2E1-M ;TFT-012CCH2E1-M;TFT-014CCH2E1-M;TFT-016CCH2E1-M
Color : White, Grey,Customizable
· Government subsidies
· Heating, Cooling and Domestic Hot Water in One System
· R290 Refrigerant More ECO-Friendly
· Meets a Variety of Terminal Usage Needs
· Full Inverter Technology
· High Efficiency, ERP Directive double A+++
· COP 5.1, Save up to 80% Energy
· Maximum Water Temperature 75°C
· Minimum ambient temperature -30 ℃
Environmental Friendliness
The Eco-friendly Heat Pump uses R290 refrigerant, which is known for its low Global Warming Potential (GWP) and zero ozone depletion potential. This natural refrigerant not only ensures high efficiency but also aligns with environmental regulations, making it a sustainable choice for heating and cooling needs. By opting for R290, users can significantly reduce their carbon footprint and contribute to global efforts towards carbon neutrality.
High Efficiency and Cost Savings
Equipped with advanced inverter technology, the SMETA Most Efficiency Heat Pump delivers exceptional energy efficiency, resulting in lower energy bills. The system’s Smart Grid Mode optimizes energy consumption by reducing peak power demand, while the PV Mode allows users to utilize solar power for additional cost savings. The heat pump’s ability to achieve a maximum water temperature of 75°C ensures that it meets a variety of heating and hot water requirements with minimal energy consumption.
Integrated System for Comprehensive Comfort
Smeta’s Air Source Heat Pump system integrates heating, cooling, and domestic hot water into a single solution, ensuring year-round comfort for residential and commercial spaces. Whether it’s heating during winter, cooling during summer, or providing hot water throughout the year, the Haier ATW Heat Pump delivers consistent performance and enhances overall living standards. The system’s compatibility with underfloor heating, fan coil units, and radiators further extends its versatility and application range.
Versatile and Reliable Operation
Designed to operate efficiently in a wide range of temperatures, the Smeta Most Efficiency Heat Pump performs reliably even in extreme weather conditions, with an operational range from -30°C to 43°C. The system’s smart defrost and anti-freezing functions ensure uninterrupted performance during cold seasons. Additionally, the heat pump is compatible with various heat sources such as solar collectors, gas furnaces, and boilers, providing flexibility and enhanced efficiency for diverse applications.
User-Friendly Interface
The Air Source Heat Pump features an intuitive user interface with easy-to-use controls, including a timer function, query parameters, and multiple operating modes (Heating, Cooling, Domestic Hot Water, etc.). The system also offers advanced features like vacation mode, child lock, and sterilization mode, providing added safety and convenience. Users can easily switch between modes and set parameters to optimize comfort and energy efficiency.
| Model No.T | TFT-008CCH2E1-M; TFT-010CCH2E1-M ;TFT-012CCH2E1-M;TFT-014CCH2E1-M;TFT-016CCH2E1-M |
| Intended use of the units | Low and medium temperature application |
| Power Supply(V/Ph/Hz) | 220-240/1/50 |
| Heating(AT7/6, WT30/35) Capacity(kW) | 8;10;12;14;16 |
| Heating(AT7/6, WT30/35) Rated power input(kW) | 1.62;2.08;2.45;2.74;3.25 |
| Heating(AT7/6, WT30/35) COP(kW/kW) | 4.95;4.8;4.9;5.11;4.92 |
| Cooling(AT35, WT23/18)Capacity(kW) | 8;10;11.4;14;16 |
| Cooling(AT35, WT23/18)Rated power input(kW) | 1.63;2.15;2.78;2.74;3.33 |
| Cooling(AT35, WT23/18)COP(kW/kW) | 4.9;4.65;4.1;5.11;4.8 |
| Season space heating energy efficiency class | A+++ |
| Water proof grade | IPX4 |
| Refrigerant | R290 |
| Certificate | CE-EMC/CE-LVD/KeyMark/NF/ROHS/POPS |
| Ambient temperature range(Cooling)°C | 10~48 |
| Ambient temperature range(Heating)°C | -30～35 |
| Ambient temperature range(DHW)°C | -30～43 |
| Net Dimensions( W*D*H )mm | 1312*470*990;1312*470*990;1312*470*990;1312*470*1370;1312*470*1370 |
| Packed Dimensions ( W*D*H )mm | 1362*567*1167;1362*567*1167;1362*567*1167;1362*567*1560;1362*567*1560 |
| Net Weight | 163;169;194 |
| Gross Weight | 171;177;205 |
| Load qty. 40HQ(pcs) | 66;33 |
